Data Center

S.No. EQUIPMENT LOCATION PURPOSE
1 DELL POWER EDGE R 710 RACK SERVER/INTEL QUAD CORE XEON 2.4GHZ X 2 / 12MB CACHE/ 12GB DDR3 RAM / 2 X 500GB 15K RPM SAS HDD /DUAL POWER SUPPLY / DVD WRITER / PERC 6I INTEGRATED RAID CONTROLLER/ 512MB CACHE WITH CONSOLE MONITOR Server room Domain controller (DC)
[Authentication authorization & Internal DNS service]
2 DELL POWER EDGE R 710 RACK SERVER/INTEL QUAD CORE XEON 2.4GHZ X 1 / 12MB CACHE/ 8GB DDR3 RAM / 2 X 500GB 15K RPM SAS HDD/ 3 X 2TB 15K RPM SAS HDD /DUAL POWER SUPPLY / DVD WRITER / PERC 6I INTEGRATED RAID CONTROLLER/ 512MB CACHE WITH CONSOLE MONITOR Server room Backup Domain controller (ADC)
[standby for DC & Backup for staff data]
3 DELL POWER EDGE R 710 RACK SERVER/INTEL QUAD CORE XEON 2.4GHZ X 2 / 12MB CACHE/ 12GB DDR3 RAM /6 X 1TB 7.2K RPM SAS HDD/DUAL POWER SUPPLY / DVD WRITER / PERC 6I INTEGRATED RAID CONTROLLER/ 512MB CACHE WITH CONSOLE MONITOR Server room Student File Server (FS)
[students of all department data except mechanical & mechatronics. Data storage for every student = 1GB]
4 DELL POWER EDGE R 710 RACK SERVER/INTEL QUAD CORE XEON 2.4GHZ X 1 / 12MB CACHE/ 8GB DDR3 RAM / 6 X 500GB 15K RPM SAS HDD/DUAL POWER SUPPLY / DVD WRITER / PERC 6I INTEGRATED RAID CONTROLLER/ 512MB CACHE WITH CONSOLE MONITOR Server room Staff File Server (SFS)
[Faculties and non-teaching staff data. Data storage for every faculty = 5GB. Data storage for every non-teachig staff =1GB]
5 DELL POWER EDGE R 710 RACK SERVER/INTEL QUAD CORE XEON 2.4GHZ X 1 / 12MB CACHE/ 32GB DDR3 RAM / 3 X 500GB 15K RPM SAS HDD/ DUAL POWER SUPPLY / DVD WRITER / PERC 6I INTEGRATED RAID CONTROLLER/ 512MB CACHE WITH CONSOLE MONITOR Server room AutoLib Server
[Library automation management software for students purpose.]
6 DELL POWER EDGE R 710 RACK SERVER/INTEL QUAD CORE XEON 2.4GHZ X 1 / 12MB CACHE/ 8GB DDR3 RAM / 3 X 500GB 15K RPM SAS HDD/DUAL POWER SUPPLY / DVD WRITER / PERC 6I INTEGRATED RAID CONTROLLER/ 512MB CACHE WITH CONSOLE MONITOR Server room Web Server
[web application and mobile applications service.]
7 DELL/OPTIPLEX 3020/INTEL (R) CORE (TM) I5 4570 CPU @ 3.20 GHZ/ 4 GB DDR3 SDRAM/500 GB HARD DISK 2. No Server room Public DNS server
[hosting our website (A) & mail (MX) record]
8 HCL INTEL CORE I3-550 /3.2 Ghz/ H55 MB/8GB DDR3 RAM/DVD writer /500GB SATA HDD Server room Microsoft SCCM
[distributing windows OS patches & antivirus end point protection definition to all windows clients]
9 DELL INTEL (R) CORE (TM) I3 4130 CPU @ 3.20 Ghz/8 GB DDR3 SDRAM/500 GB SATA HDD Server room Parent corner
[Student Attendance, Marks-Assignments, Slip test, Cycle test, University, Time table - class & exam, Hall ticket Generation, Progress report, web portal calculation, Chairperson analysis report, Mentor-Mentee report etc
10 WIPRO INTEL XEON 3Ghz /1GB DDR RAM/ 2 x 72GB SCSI HDD Server room Internal application server
[LMS, BONAFIDE,HALL BOOKING, TRANSPORT BOOKING]
11 SOPHOS XG310 FIREWALL Server room Distributing Internet service from Vodafone & Reliance jio
12 ATEN 8 PORT COMBO KVM switch - 2.no Server room To connect multiple servers with the same monitor & keyboard.
13 HP E5406ZL SWITCH/ 12-PORT GIG-T/ 12-PORT SFPV2 ZL MODULE/ HP X1211G SFP LC LX TRANSCEIVER/HP E-MSM765 ZL MOBILITY CONTROLLER Server room Core switch
To connect fiber links from all Department
14 HP 5120 EI SWITCH Server room To connect all the servers with Core Switch.
15 Maruthi 10KVa online UPS
Numeric 15KVa online UPS		 Server room To provide uninterrupted current when the mains fail


Internet Connectivity:

Name of the Internet provider Vodafone, Reliance jio
Available of Band width Vodafone - 300Mbps
Reliance jio - 10Mbps
Number of Internet Services Two
Wi Fi availability 24x7 (Access point - 96 No)




CAMPUS wide cloud service  Microsoft Office365 for education

Google workspace for education fundamentals

Google Workspace for Education: Teaching and Learning Upgrade

Supporting Staffs

S.No. Photo Name Designation
1 Balasubramanian.S
Ph - 9710092860
Mail - systemadmin@kamarajengg.edu.in		 System Administrator
2 Balaji.B Instructor
3 Karuppasamy.S Technician
